Cutting edge compressors

Our compressors are unique for their compact size, high efficiency, and exceptional reliability. We provide solutions for a wide range of pressure ratios, mass flows, and operating conditions. With 10+ years of innovation and extensive customer collaborations, we have the right solutions to answer your needs.

  • Design – Minimal size and weight
  • Performance – Highest efficiency and capabilities
  • Reliability – Longest operating hours and start/stop cycles
  • Solution – Compressor and converter out of one hand
  • Flexibility – Flexible design and custom solutions

Turbo compressors with gas bearings for air

TypeRated powerRated speedPressure ratioMass flowIsentropic overall efficiencyWeight Datasheet.step File
Turbo Kompressor für Gaslagerung mit LuftCTi-10001,000 W280,000 rpm1.6515 g/s55 %2 kg
Turbo Kompressor für Gaslagerung mit LuftCTi-10011,200 W280,000 rpm1.6521 g/s59 %2 kg
Turbo Kompressor für Gaslagerung mit LuftCTi-11001.5 kW260,000 rpm1.917 g/s3.5 kg
Turbo Kompressor für Gaslagerung mit LuftCTi-11011.5 kW260,000 rpm1.723 g/s3.5 kg
Turbo Kompressor für Gaslagerung mit LuftCTi-20015.5 kW170,000 rpm2.540 g/s8.6 kg
CT-25-10000.GB7 kW150,000 rpm2.190 g/s64 %8.8 kg
CT-22-12000.GB12 kW150,000 rpm2.1140 g/s65 %10 kg
CT-20008 kW170,000 rpm2.290 g/s65 %6.3 kg
CT-300019 kW130,000 rpm2.6155 g/s65 %18.5 kg
CT-300121 kW130,000 rpm2.7210 g/s69 %18.5 kg
CTE-400025 kW120,000 rpm3.1210 g/s19 kg

Specific aerodynamic or electrical requirements?
